LumiCure Light
1 / 3
The principle of UV curing is that ultraviolet rays are irradiated with special glue to cause polymerization of the glue to solidify. Different sizes of cured articles require different sizes of curing machines. Portable style, desktop case style, hanging style for industrial production, and large curing machine for large items are available. The speed adjustment drive keeps the speed of the conveyor belt uniform under different loads of the UV machine. The UV machine is equipped with a high-intensity light source.
| Model | MD-U15 | MD-U20 | MD-U50 |
|---|---|---|---|
| Supply | AC 220V/50Hz | ||
| Total length | 1500mm | 2000mm | 5000mm |
| Belt width | 400mm | 600mm | 1200mm |
| Feeding width | 350mm | 550mm | 1150mm |
| Product height | 100mm | 100mm | 300mm |
| Speed | 0-10m/min (adjust) | 0-10m/min (adjust) | 0-100m/min (adjust) |
| Number of UV lamps | 2 PCS | 4 PCS | 6 PCS |
| Lamp power | 30 W | 80 W | 500KW |
| Light Wavelength | 365nm | ||
| Machine size | L1200*W520*H670mm | - | - |
| Weight | 60kg | - | - |
