LumiCure Light
1 / 5
Scope of Application: UV coating, hardware, screen printing, glass, plastic, surface finishing, UV inks, coating experiments, etc. With higher UV energy, the coating has stronger penetration capability. Our UV LAMP has high UV frequency. It fits almost all UV INKS and UV glues. Our UV Lamp has a guaranteed useful lifespan of 1000-1200 hours. The machine features speed change adjustment with a belt running speed of 0-10M/min.
Due to product upgrades or customization needs, the final appearance and parameters of the machine may change slightly.
| Technical Specifications | |
|---|---|
| Model | NT-1500A |
| Belt size | 1500*500mm |
| Power | 3.5KW |
| Voltage | 220V/380V |
| Working area | 700mm |
| Height of entrance | 100-200mm |
| Height of lamp | 100-200mm (adjustable) |
| Feeding area | 400mm |
Manual height adjustment between 100-200mm to suit processing requirements.
Used for precise monitoring and measuring of AC voltage during operation.
High-quality, durable belt designed for smooth heat-resistant conveying.
Integrated ventilation system to effectively extract heat and discharge harmful gases.
This machine is widely used for UV coating, hardware processing, screen printing, glass, plastic, surface finishing, curing UV inks, and conducting coating experiments.
Yes, the conveyor belt speed is steplessly adjustable from 0 to 10 meters per minute. The lamp height can be adjusted manually between 100mm and 200mm to match different item profiles.
The machine features built-in abnormal lamp protection, over-voltage and over-current protection, system overload protection, and instant fault alarm prompts to ensure safe operation.
The high UV frequency lamp has an expected operational lifespan of approximately 1000 to 1200 hours under normal operating conditions.
The machine is equipped with a specially designed ventilation system inside the light box paired with a forced wind combination exhauster set to effectively cool the system and exhaust harmful process gases.
Inspect the packaging upon delivery. If damage is found, do not sign for the shipment and register a complaint with the carrier immediately. Please contact customer support with damage details within 24 hours.
