| Product Name | UV LED Curing Machine | |||
| Product Model | LS400-LED365 | LS400-LED385 | LS400-LED395 | LS400-LED405 |
| Machine Power | 800W | |||
| Lamp Power | 720W | |||
| Peak Wavelength | 365nm | 385nm | 395nm | 405nm |
| Irradiation Area | 150*350mm | |||
| Lamp Bead Amount | 360pcs | |||
| Irradiation Distance | 10-30mm adjustable | |||
| Control Methods | Button control or I/O Control, can choose | |||
| Power Regulation | 1-100% power adjustable | |||
| Machine Size | 1000*610*780mm | |||
| Input Power | AC 220V, 50/60HZ | |||
| Equipment Application | Medical, electronic, liquid crystal, PCB, packaging and other UV glue curing | |||
This UV LED curing machine is available in four standard models: LS400-LED365, LS400-LED385, LS400-LED395, and LS400-LED405, corresponding to different curing wavelengths.
The equipment supports four peak wavelength selections depending on your process requirements: 365nm, 385nm, 395nm, and 405nm.
It features an irradiation area of 150*350mm. The irradiation distance is adjustable between 10mm and 30mm for optimal curing performance.
The machine features 1-100% adjustable power regulation and can be operated via either convenient Button control or external I/O Control options.
This system is widely used for UV glue and screen printing ink curing in medical, electronic, liquid crystal, PCB, packaging, and other related industries.
It operates on an input power of AC 220V (50/60HZ). The total machine power is 800W, with a dedicated lamp power of 720W, and the machine dimensions are 1000*610*780mm.
